- M.2 NVMe to U.2(SFF-8639) convert
- PCIe to U.2(SFF-8639) convert
- Build in M.2 M-key Female connector
- Build in SFF-8639 connector, pin-out defined by PCIe
- Build in PCIe x4 slot connector
- PWM synchronous buck converter Power IC for M.2
※ 4A maximum output current
※ Short circuit protection
※ In-rush current suppression
※ Thermal shutdown protection
※ ESD HBM (Human Body Mode)/2KV
- LED2 Green LED on indicates M.2 NVMe SSD power ready
- LED1 RED LED Blinking indicates M.2 SSD active status
